To Attach a Datum Identifier Symbol to a Feature Control Frame

How to create a datum identifier symbol that is attached to a feature control frame symbol.

1. Click Annotate tabSymbol panelDatum Identifier. Find
2. In the drawing area, select the feature control frame to attach to.
3. On the feature control frame, specify the start point of the leader.
4. In the Datum Identifier dialog box, enter the identifying letters.
5. Click OK.
