The Infrastructure Map Server component hosts the Infrastructure Map Server services and responds to requests from client applications through TCP/IP protocol.
You can manage your site and its servers with the Site Administrator program. This program is installed with the Web Server Extension. It has a Web-based interface that you can access from any web browser. To start the program, you open a browser and enter: http://servername:port/mapserver2012/mapadmin/login.php, using the name or IP address of the server on which you installed the Web Server Extension.
When you log onto the Site Administrator program, you can:
- Manage your site. For example, you can add and remove servers, or take them offline for maintenance.
- Assign services to the servers. For example, one server can process mapping requests while another handles rendering tasks.
- Monitor the status of any server.
- Define users and groups and assign roles and access permissions to them.
The illustration shows two views of the Site Administrator program. The upper image shows the home page, which lists the servers in the site. The lower image shows a typical list of users and the groups that they belong to.
Two views of the Site Administrator program
