Add Layers to a Map

In this exercise, you add layers to the map and preview the results.

	Detailed steps
	In the Site Explorer, double-click Sheboygan City Map to open it. If it is already open, click its tab to view it. On the Infrastructure Studio toolbar, click Edit to hide the preview panel. Close the Settings panel by clicking the minus (-) sign, so that you can see more of the Layers panel.
	In the Site Explorer, select the Parcels layer and drag it to the list of layers in the Layers panel. Drag the CENTLINES layer to the list.
	On the toolbar, click Split to show the Preview panel. Click Refresh in the Preview panel. The two layers should appear correctly. Zoom in and out to test the scale ranges that you applied to the CENTLINES layer. On the toolbar, click Save to save the map resource.
