After using the Show Hidden Lines tool to display lines of model elements and detail elements that are obscured by other elements, you can use Remove Hidden Lines to reverse that setting.
The following example illustrates the results after selecting View tab
Graphics panel
(Remove Hidden Lines), and then selecting the 4x6 stud and the bolt. This procedure removes the hidden lines, and the 4x6 stud completely obscures the bolt.
Architectural example
Structural example
