Standard snaps let you snap to mesh and shape objects, as well as to the active grid.
Non-grid snap types, when active, take priority over Grid Points and Grid Lines snaps: if the mouse is equally near a grid point and some other snap type, it will choose the other snap type.
-
Grid Points -
Snaps to grid intersections. This snap type is on by default.
- Grid Lines
-
Snaps to any point on a grid line.
Pivot-
Snaps to pivot points of objects.
- Bounding Box
-
Snaps to one of the eight corners of an object's bounding box.
- Perpendicular
-
Snaps to the perpendicular point on a spline, relative to the previous point.
- Tangent
-
Snaps to a tangent point on a spline, relative to the previous point.
Vertex-
Snaps to vertices of mesh objects or objects that can be converted to editable meshes. Snaps to segments on splines.
-
Endpoint -
Snaps to the end points of edges on meshes or spline vertices.
-
Edge/Segment -
Snaps anywhere along edges (visible or invisible) or spline segments.
-
Midpoint -
Snaps to the middle of edges on meshes and spline segments.
-
Face - Snaps anywhere on the surface of a face. Back faces are culled, so they have no effect.
- Center Face
-
Snaps to the center of triangular faces.
