Imager White Balance - Arnold User Guide
Use the white balance imager to correct the image's white balance with reference illuminants, custom colors, or a blackbody temperature.
Input
Input points to the previous imager operation in the chain (so that you can stack them and apply multiple operations serially).
Enable
Enables this imager.
Layer Selection
Selects layers processed by this imager with a glob or operator expression. An imager can use a selection to determine whhich AOVs will be selected to be processed by the imager at render time. The selection is an expression that can consist of multiple selections concatenated by:
or(union)and(intersection)not(negation)and not(exclusion)()for nested scoping
Each selection uses glob patterns and regular expressions and a node will be processed by the imager if the expression matches the node name. By default, glob matching is used unless the selection is in a regex quote, i.e. r'<my_regex>'. For example:
specular or diffuse not r'sss_(direct|indirect)' r'color_(mask1|mask2)' or r'mask[34]'
Mode
White balance mode.
Temperature
Temperature for black body mode.
| Light Type | Color Temperature in Kelvin | Hue |
|---|---|---|
| Overcast daylight | 6000 K | 130 |
| Noontime sunlight | 5000 K | 58 |
| White fluorescent | 4000 K | 27 |
| Tungsten/halogen lamp | 3300 K | 20 |
| Incandescent lamp (100 to 200 W) | 2900 K | 16 |
| Incandescent lamp (25 W) | 2500 K | 12 |
| Sunlight at sunset or sunrise | 2000 K | 7 |
| Candle flame | 1750 K | 5 |
 |
 |
 |
 |
 |
| 1750 | 2000 | 2500 | 2900 | 3300 |
 |
 |
 |
 |
|
| 4000 | 5000 | 6000 | 6500 |
Illuminant
Standard illuminant name for illuminante mode.
 |
 |
 |
 |
 |
|---|---|---|---|---|
| daylight (default) | sun | shade | overcast | fluorescent |
 |
 |
 |
 |
 |
| cie a | cie 50 | cie 55 | cie 65 | cie 75 |
 |
 |
 |
 |
 |
| cie f1 | cie f2 | cie f3 | cie f4 | cie f5 |
 |
 |
 |
 |
 |
| cie f6 | cie f7 | cie f8 | cie f9 | cie f10 |
 |
 |
 |
 |
 |
| cie f11 | cie f12 | halogen warm | halogen basic | halogen cool |
 |
 |
 |
 |
 |
| ceramic halide warm | ceramic halide cool | quartz halide warm | quartz halide | quartz halide cool |
 |
 |
 |
 |
 |
| mercury | phosphor mercury | xenon | high press sodium | low press sodium |
 |
||||
| cie a |
Custom
Custom white balance color.
