Share Email Facebook Twitter LinkedIn What's New in Revit LT 2021 Learn about new features in Autodesk Revit LT 2021. For technical details, see the release notes. FilterSelect...cloud (3)collaboration (4)community idea (4)data exchange (5)discipline-architecture (6)discipline-platform (13)documentation (2)enhanced functionality (4)modeling (6)parameters/properties (4)performance (3)productivity (3)user interface (3)video available (1)visibility/graphics (2)visualization (2)workflows (5) 2021.1 Release Shared Views Share models with project stakeholders in the cloud. Shared views allows you to share you model with anyone, even if they do not have Revit. Technology Preview: Load Autodesk Family Use a custom browser to find and load Autodesk content from the cloud into your model. Search the default content libraries across multiple languages to find just the right family. Export STL Export your models from Revit to an STL file without an add-on. Use the STL file for 3D printing your models. Enhanced FormIt Converter Visual and material fidelity of models converted from FormIt and opened in Revit have been enhanced. Improved CAD Import Improvements make importing SAT and Rhino files more reliable than in previous releases. SketchUp 2020 Support Added support for the import of 2020 format SketchUp files. Additional Unit Types To better support information workflows, many new unit types are available for use in parameters. User Interface Improvements Revit 2021.1 includes a number of user interface improvements to make working easier. 2021 Release Highlights Enhanced Realistic Views This feature provides a superior replacement for realistic views. Slanted Walls Create slanted walls and slanted curtain walls using the standard Wall tool. Slanted walls can host elements like doors, windows, electrical features, wall sweeps, and more. Link Images Link a raster image into a 2D view for reference without increasing the size of the model or affecting performance. Then remove the file when it's no longer needed. Cloud Models on Europe Data Centers Cloud models can now be hosted on Europe data centers. More features Display Contrasting Rows in a Schedule To make a large schedule easier to read, set the Stripe Rows feature to display rows in contrasting colors. Simplified Shared Coordinates To more easily work with linked models, you can display coordinates of linked models in the host model. These coordinates include the survey point, project base point, and internal origin. Rotate Text in Tags, Section Heads The family parameter Rotate with Component has been added to more tag categories. In addition, text rotation in section heads is improved. Performance Improvements Revit LT 2021 includes several performance improvements. Design Options Enhancements In the Design Options dialog, option sets and design options are automatically sorted in alphanumeric order. Cuts Geometry Parameter for Voids Voids used in families have a new parameter: Cuts Geometry. Unit Type for US Survey Feet To better support infrastructure design, Revit LT supports decimal US survey feet as a length unit.
