Adds leader lines to, or removes leader lines from, a multileader object.
Access Methods
Button
Toolbar: Annotation tool set
Leaders tool group Add Leader, Remove Leader Menu:
Modify
Object
Multileader
Add Leader
Pointing device: Hover over Landing grip and choose Add Leader; hover over leader endpoint grip and choose Remove Leader
List of Prompts
The following prompts are displayed.
Specify leader arrowhead location or [Remove Leaders]
- Add Leader
-
Adds a leader line to a selected multileader object. The new leader line is added to the left or right of the selected multileader, depending on the location of the cursor.
- Remove Leaders
-
Removes a leader line from a selected multileader object.
For example:
