Use this dialog to define a new style or modify an existing style of a detail. To access this dialog, click New or Modify in the Styles of symbols dialog when a detail symbol style is selected in the Symbol field.
Define the following settings for graphic parameters of a detail symbol:
- detail border
line type
color
thickness
- description location
- text
style
color
size
name syntax used for defined details; in the Prefixfield type the word Detail, for example, which is customary used to describe a detail in the drawing
numbering.
