Use the raised-round toolpath to machine precise, recessed shapes in several concentric passes using a selection of vector artwork.
Click the
Create Raised Round Toolpath
button on the
Toolpaths panel to display the
Raised Round panel. Use the
Raised Round panel to:
- set the perimeter outline of the recess using a vector's boundary;
- specify the depth of the recess;
- control the cross-section of the recess using an interactive half-profile; and
- choose whether to machine inwards from a vector's boundary, or outwards from a vector's centre.
After you have calculated the toolpath, you can simulate it.
