Plot Popup (for setting options only). More...
#include <pyfbsdk.h>
Public Member Functions | |
FBPlotPopup () | |
Constructor. | |
FBPlotOptions | GetPlotOptions () |
Get plot options. | |
bool | Popup (str pWindowName) |
Execute plot popup. | |
SetPlotOptions (FBPlotOptions pPlotOptions) | |
Set plot options. | |
![]() | |
FBVisualComponent () | |
Constructor. | |
bool | AddChild (FBVisualComponent pChild, int pId=0) |
Add a child component. | |
FBVisualComponent | GetChild (int pId=0) |
Get a child component. | |
QWidget | GetQWidgetAddress () |
Get internal QWidget. | |
bool | IsView () |
Is component a view? | |
Refresh (bool pNow=False) | |
Refresh component. | |
ViewExpose () | |
Exposed view callback function. | |
ViewInput (int pMouseX, int pMouseY, FBInputType pAction, int pButtonKey, int pModifier) | |
Input callback function. | |
![]() | |
FBComponent () | |
Constructor. | |
str | ClassName () |
Get the class name. | |
DisableObjectFlags (FBObjectFlag pFlags) | |
Disable a specific Object Flags. | |
EnableObjectFlags (FBObjectFlag pFlags) | |
Enable a specific Object Flags. | |
bool | FBCreate () |
Open Reality Creation function. | |
FBDelete () | |
Open Reality deletion function. | |
FBDestroy () | |
Open Reality destruction function. | |
FBObjectFlag | GetObjectFlags () |
Get all Object Flags (concatenated). | |
bool | GetObjectStatus (FBObjectStatus pStatus) |
Check to see if an object status is enabled. | |
FBFileReference | GetOwnerFileReference (p0) |
Get the owner FileReference object. | |
HardSelect () | |
HardSelect. | |
bool | HasObjectFlags (FBObjectFlag pFlags) |
Check whether a specific object flag is enabled. | |
bool | Is (int pTypeId) |
Returns true if object is of type TypeId. | |
bool | ProcessNamespaceHierarchy (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True) |
ProcessNamespaceHierarchy. | |
bool | ProcessObjectNamespace (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True) |
ProcessObjectNamespace. | |
int | PropertyAdd (FBProperty pProperty) |
Add a property to the component's property manager. | |
bool | PropertyAddReferenceProperty (FBProperty pReferenceProperty) |
Add a reference property to the component's property manager. | |
FBProperty | PropertyCreate (str pName, FBType pType, str pDataType, bool pAnimatable, bool pIsUser=False, FBProperty pReferenceSource=None) |
Create user or dynamic property. | |
PropertyGetModifiedList (FBArrayTemplate< FB > pPropList, FBPlugModificationFlag pModificationFlags) | |
Get list of properties which have been modified since last loading. | |
PropertyRemove (FBProperty pProperty) | |
Remove a Property from the component's Property manager. | |
SetObjectFlags (FBObjectFlag pFlags) | |
SetObjectFlags. | |
SetObjectStatus (FBObjectStatus pStatus, bool pValue) | |
Enable/Disable a specific Object Status. | |
Public Attributes | |
bool | EnableEvaluateDeformation |
Read Write Property: Enable Evaluate Deformation option for popup. | |
bool | EnablePlotAuxEffectors |
Read Write Property: Enable Plot Aux Effectors option for popup. | |
bool | EnablePlotCharacterExtension |
Read Write Property: Enable Plot Character Extension option for popup. | |
bool | EnablePlotLockedProperties |
Read Write Property: Enable Plot Locked Properties option for popup. | |
bool | EnablePlotTranslationOnRootOnly |
Read Write Property: Enable Plot Translation On Root Only option for popup. | |
bool | EnableSmartPlotControls |
Read Write Property: Enable Smart Plot option for popup. | |
![]() | |
str | RegionName |
Read Write Property: Region name. | |
int | RegionOffsetX |
Read Write Property: Region X offset. | |
int | RegionOffsetY |
Read Write Property: Region Y offset. | |
int | RegionOffsetWidth |
Read Write Property: Region width offset. | |
int | RegionOffsetHeight |
Read Write Property: Region height offset. | |
float | RegionRatioX |
Read Write Property: Ratio for X attachment. | |
float | RegionRatioY |
Read Write Property: Ratio for Y attachment. | |
float | RegionRatioWidth |
Read Write Property: Ratio for Width attachment. | |
float | RegionRatioHeight |
Read Write Property: Ratio for Height attachment. | |
FBAttachType | RegionAttachTypeX |
Read Write Property: X Attachment type. | |
FBAttachType | RegionAttachTypeY |
Read Write Property: Y Attachment type. | |
FBAttachType | RegionAttachTypeWidth |
Read Write Property: Width Attachment type. | |
FBAttachType | RegionAttachTypeHeight |
Read Write Property: Height Attachment type. | |
FBVisualComponent | RegionAttachToX |
Read Write Property X Attachment source. | |
FBVisualComponent | RegionAttachToY |
Read Write Property: Y Attachment source. | |
FBVisualComponent | RegionAttachToWidth |
Read Write Property: Width Attachment source. | |
FBVisualComponent | RegionAttachToHeight |
Read Write Property: Height Attachment source. | |
int | RegionPosMaxX |
Read Write Property: Region X position Max | |
int | RegionPosMinX |
Read Write Property: Region X position Min | |
int | RegionPosMaxY |
Read Write Property: Region Y position Max | |
int | RegionPosMinY |
Read Write Property: Region Y position Min | |
str | BorderCaption |
Read Write Property: Caption to display in border. | |
bool | BorderShowCaption |
Read Write Property: Show caption? | |
FBBorderStyle | BorderStyle |
Read Write Property: Style of border. | |
bool | BorderInSet |
Read Write Property: Is border inset? | |
int | BorderWidth |
Read Write Property: Width of border. | |
int | BorderSpacing |
Read Write Property: Spacing of border. | |
float | BorderMaxAngle |
Read Write Property: Max angle for rounding. | |
int | BorderCornerRadius |
Read Write Property: Corner radius (rounded). | |
str | Caption |
Property: Widget caption. | |
bool | Enabled |
Read Write Property: Is visual enabled? | |
int | Height |
Read Write Property: Height. | |
str | Hint |
Read Write Property: Hint to show. | |
int | Left |
Read Write Property: Left coordinate. | |
bool | ReadOnly |
Read Write Property: Is visual component read only? | |
int | Top |
Read Write Property: Top coordinate. | |
bool | Visible |
Read Write Property: Is visual component visible? | |
int | Width |
Read Write Property: Width. | |
![]() | |
FBListComponent | Components |
List: List of components. | |
str | LongName |
Read Write Property: Name and namespace for object. | |
str | Name |
Read Write Property: Unique name of object. See sample: RemoveSuffixFromNameOfSceneElements.py. | |
FBListComponent | Parents |
List: Parents. | |
FBManager | PropertyList |
Read Only Property: Manages all of the properties for the component. | |
bool | Selected |
Read Write Property: Selected property. | |
int | TypeInfo |
Contains the Type information of the object. | |
![]() | |
str | ClassGroupName |
ClassGroupName of the object. | |
int | TypeInfo |
TypeInfo. | |
FBPlotPopup | ( | ) |
Constructor.
FBPlotOptions GetPlotOptions | ( | ) |
Get plot options.
SetPlotOptions | ( | FBPlotOptions | pPlotOptions | ) |
Set plot options.
pPlotOptions | Set the plot options that will be used when displaying the plot popup. First use the GetPlotOptions(), change the options and use the SetPlotOptions() to set them before calling the Popup() function. |
bool EnableEvaluateDeformation |
Read Write Property: Enable Evaluate Deformation option for popup.
bool EnablePlotAuxEffectors |
Read Write Property: Enable Plot Aux Effectors option for popup.
bool EnablePlotCharacterExtension |
Read Write Property: Enable Plot Character Extension option for popup.
bool EnablePlotLockedProperties |
Read Write Property: Enable Plot Locked Properties option for popup.
bool EnablePlotTranslationOnRootOnly |
Read Write Property: Enable Plot Translation On Root Only option for popup.
bool EnableSmartPlotControls |
Read Write Property: Enable Smart Plot option for popup.
