Analytical floor panels can now be automatically aligned to their supporting elements. You can control the adjustment process to preserve features such as balconies while ensuring analytical contours accurately reflect structural support conditions.
When the distance between a floor edge and another analytical element is too small, the contour refines automatically. This ensures the physical and analytical structures fit without manual cleanup in your structural analysis solution.
- Reduce manual adjustments before running analysis
- Maintain a cleaner, more analysis-ready analytical model
- Spend less time fixing geometry in your structural analysis tool
This automation eliminates a repetitive, error-prone task and helps you move from modeling to analysis faster and with more confidence.
This feature was suggested by customers on the
Ideas forum and is described on the
product road map.
See Align Analytical Model for Entire Buildings with Grids and Levels.
