API: Expose Property Line API

New methods and properties have been added to the PropertyLine class to enhance third-party workflows involving Property Lines in projects. Previously, the PropertyLine class was exposed without its own dedicated methods and properties.

The exposed API provides full support for Property Line functionality available in the UI, including:

• Create and edit through sketch
• Create and edit through the Property Table
• Convert sketches to Property Table representations
• Schedule, tag, and export Property Line data

• Newly Exposed API Members for PropertyLine

  Methods (12)

  The following methods are now exposed:

  public static PropertyLine Create(Document document, IList<CurveLoop> curveLoops)
  public static PropertyLine Create(Document document,IList<PropertyTableEntry> pt)
  public static bool IsValidBoundary(IList<CurveLoop> curveLoops)
  public static bool IsValidPropertyTable(Document document,IList<PropertyTableEntry> pt)
  public void ConvertToTable()
  public XYZ GetStart()
  public void SetStart(XYZ start)
  public void SetBoundary(IList<CurveLoop> curveLoops)
  public IList<CurveLoop> GetBoundary()
  public void SetPropertyTable(IList<PropertyTableEntry> newTable)
  public IList<PropertyTableEntry> GetPropertyTable()
  public bool IsClosedLoop()


  Property (1)

  The following property is now exposed:

  public double Area { get; }

• The PropertyTableEntry class has been exposed to enable access to row-level Property Table data.

  PropertyTableEntry Exposed Properties	PropertyTableEntry Exposed Methods
  public double Distance { get; } public double Bearing { get; } public int Id { get; set; } public PropertyTableEntryArcDirection ArcDirection { get; } public double Radius { get; } public PropertyTableEntryCurveType CurveType { get; }	public static PropertyTableEntry Create(     double distance,     double bearing,     PropertyTableEntryCurveType curveType,     double arcRadius,     PropertyTableEntryArcDirection arcDir,     int id ) public static bool IsValidPropertyTableEntry(     double distance,     double bearing,     PropertyTableEntryCurveType curveType,     double arcRadius,     PropertyTableEntryArcDirection arcDir )

See Revit API Developers Guide.

This feature was suggested by customers on the Ideas forum and is described on the product road map.
