Upload and Assign Images (MEP Fabrication Data Manager - Tech Preview) (What's New in 2025)

Upload images or generate them from the model and assign them to parts to make parts more visually identifiable.

  • Generate from 3D model will take a snapshot of the current view, including the environment.
  • Upload File: Upload common image files and use the cropping tool to size and position as desired.

See Technology Preview: Fabrication Data Manager and the MEP Fabrication Data Manager Help.
