Story Track class. More...
#include <pyfbsdk.h>
Public Member Functions | |
FBStoryTrack (FBStoryTrackType pTrackType, FBStoryFolder pFolder=None) | |
Constructor. | |
FBStoryTrack (FBComponent pSource, FBStoryFolder pFolder=None) | |
Constructor. | |
AddClip (FBComponent pClip, FBTime pTime) | |
AddClip Add the clip to the track. | |
ChangeDetailsBegin () | |
ChangeDetailsBegin. | |
ChangeDetailsEnd () | |
ChangeDetailsEnd. | |
FBStoryClip | CopyTakeIntoTrack (FBTimeSpan pTimeSpan, FBTake pTake, FBTime pOutputOffset=0, bool pMakeUndoable=False) |
CopyTakeIntoTrack Copy animation from the specified take for affected objects of the track. | |
FBStoryClip | CopyTakeIntoTrack (FBTimeSpan pTimeSpan, FBTake pTake, bool pConnectToCurrentTake, FBTime pOutputOffset=FBTime(0), bool pMakeUndoable=False) |
CopyTakeIntoTrack Copy animation from the specified take for affected objects of the track. | |
FBStoryTrack | CreateSubTrack (FBStoryTrackType pTrackType, FBStoryTrackRefMode pRefMode) |
Create a sub track, Only Character and Animation tracks can have sub-tracks. | |
EnableBodyPart (FBStoryTrackBodyPart pPart, bool pEnable) | |
EnableBodyPart. | |
FBDelete () | |
Virtual FBDelete function. | |
bool | IsBodyPartEnabled (FBStoryTrackBodyPart pPart) |
IsBodyPartEnabled. | |
Load (bool pLoad) | |
Allow to load/unload all story clips under this track. | |
bool | PlotToCameraSwitcher (FBTake pTake) |
PlotToCameraSwitcher Plot the Shot Track to the Camera Switcher on the given Take. | |
![]() | |
FBConstraint (str pName) | |
Constructor. | |
FBAnimationNode | AnimationNodeInCreate (kReference pUserId, FBModel pModel, str pAttribute) |
FBAnimationNode | AnimationNodeInCreate (kReference pUserId, FBProperty pProperty) |
Animation Node Creations (IN). | |
FBAnimationNode | AnimationNodeOutCreate (kReference pUserId, FBModel pModel, str pAttribute) |
Animation Node Creations (IN/OUT). | |
FBConstraint | Clone () |
Clone the constraint. | |
bool | DeformerBind (FBModel pModel) |
Bind/Unbind pModel to deformation constraint. | |
bool | DeformerUnBind (FBModel pModel) |
bool | Disable (FBModel pModel) |
Disable constraint on pModel. | |
FreezeSRT (FBModel pModel, bool pS, bool pR, bool pT) | |
Freeze current model state. | |
FreezeSuggested () | |
Suggest 'freeze'. | |
bool | ReferenceAdd (int pGroupIndex, FBModel pModel) |
Add a reference to a specified group. | |
FBModel | ReferenceGet (int pGroupIndex, int pItemIndex=0) |
Get a reference. | |
int | ReferenceGetCount (int pGroupIndex) |
Get number of references in a specified group. | |
int | ReferenceGroupAdd (str pGroupName, int pMaxItemCount) |
Add a group of references. | |
int | ReferenceGroupGetCount () |
Return the number of reference groups. | |
int | ReferenceGroupGetMaxCount (int pGroupIndex) |
Get the maximum number of items that can exist in the reference group in question. | |
str | ReferenceGroupGetName (int pGroupIndex) |
Get the name of the reference group. | |
bool | ReferenceRemove (int pGroupIndex, FBModel pModel) |
Remove a reference to pModel from the group at pGroupIndex. | |
RemoveAllAnimationNodes () | |
Remove animation nodes. | |
RestoreModelState (FBModel pModel) | |
Restore the saved model state onto pModel. | |
SaveModelState (FBModel pModel, bool pS, bool pR, bool pT) | |
Save current state of pModel. | |
SetupAllAnimationNodes () | |
Setup animation nodes. | |
SnapSuggested () | |
Suggest 'snap'. | |
![]() | |
FBBox (str pName) | |
Constructor. | |
bool | AnimationNodeDestroy (FBAnimationNode pAnimationNode) |
Destroy an animation node. | |
FBAnimationNode | AnimationNodeInGet () |
Get the (IN/OUT) animation node for this box. | |
bool | AnimationNodeIsUserData (FBAnimationNode pAnimationNode) |
Is the animation node user data? | |
FBAnimationNode | AnimationNodeOutGet () |
str | FbxGetObjectSubType () |
Returns the class sub type inherited by the class of an object, for example: 'Relations', 'Parent-Child', 'Number to Vector', 'Shot'. | |
str | FbxGetObjectType () |
Returns the class type inherited by the class of an object, for example: 'Box', 'Constraint', 'TimelineXTrack'. | |
FBAnimationNode | GetInConnector (int pIndex) |
Get the animation node input associated with the given index. | |
int | GetInConnectorCount () |
Get the number of animation node inputs for this box. | |
FBAnimationNode | GetOutConnector (int pIndex) |
Get the animation node output associated with the given index. | |
int | GetOutConnectorCount () |
Get the number of animation node outputs for this box. | |
![]() | |
FBComponent () | |
Constructor. | |
str | ClassName () |
Get the class name. | |
DisableObjectFlags (FBObjectFlag pFlags) | |
Disable a specific Object Flags. | |
EnableObjectFlags (FBObjectFlag pFlags) | |
Enable a specific Object Flags. | |
bool | FBCreate () |
Open Reality Creation function. | |
FBDelete () | |
Open Reality deletion function. | |
FBDestroy () | |
Open Reality destruction function. | |
FBObjectFlag | GetObjectFlags () |
Get all Object Flags (concatenated). | |
bool | GetObjectStatus (FBObjectStatus pStatus) |
Check to see if an object status is enabled. | |
FBFileReference | GetOwnerFileReference (p0) |
Get the owner FileReference object. | |
HardSelect () | |
HardSelect. | |
bool | HasObjectFlags (FBObjectFlag pFlags) |
Check whether a specific object flag is enabled. | |
bool | Is (int pTypeId) |
Returns true if object is of type TypeId. | |
bool | ProcessNamespaceHierarchy (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True) |
ProcessNamespaceHierarchy. | |
bool | ProcessObjectNamespace (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True) |
ProcessObjectNamespace. | |
int | PropertyAdd (FBProperty pProperty) |
Add a property to the component's property manager. | |
bool | PropertyAddReferenceProperty (FBProperty pReferenceProperty) |
Add a reference property to the component's property manager. | |
FBProperty | PropertyCreate (str pName, FBType pType, str pDataType, bool pAnimatable, bool pIsUser=False, FBProperty pReferenceSource=None) |
Create user or dynamic property. | |
PropertyGetModifiedList (FBArrayTemplate< FB > pPropList, FBPlugModificationFlag pModificationFlags) | |
Get list of properties which have been modified since last loading. | |
PropertyRemove (FBProperty pProperty) | |
Remove a Property from the component's Property manager. | |
SetObjectFlags (FBObjectFlag pFlags) | |
SetObjectFlags. | |
SetObjectStatus (FBObjectStatus pStatus, bool pValue) | |
Enable/Disable a specific Object Status. | |
Public Attributes | |
bool | AcceptKey |
Read Write Property: Allow track to accept keys | |
int | AudioOutIndex |
Read Write Property: Audio Output's index to use. | |
FBCharacter | Character |
Read Write Property: Character to use. | |
int | CharacterIndex |
Read Write Property: Character's index to use. | |
str | ClipNameConvention |
Read Write Property: Naming convention for each new recording clip that is created. Can use special tags: <Name> <StartTCValue> <StartFrameValue> <StartDate> <StartTime> <TakeName> | |
FBListStoryClip | Clips |
List: Clips contained in this track. | |
FBListStoryDetails | Details |
List: All objects associated to this track for processing. | |
bool | Ghost |
Read Write Property: Show ghosts | |
bool | GhostModel |
Read Write Property: Show ghost of models | |
bool | GhostPivot |
Read Write Property: Show ghost of match object | |
FBStoryTrackGhostShowMode | GhostShowTrackMode |
Read Write Property: Show the ghosts for all the clips or only the adjacent clips. See FBStoryTrackGhostShowMode | |
bool | GhostTravelling |
Read Write Property: Show ghost of clip vector or traveling node | |
str | Label |
Read Write Property: Label to display for this story track. | |
bool | Mute |
Read Write Property: If true, this track wont' play. | |
bool | OffsetEnable |
Read Write Property: When enabled, allow clip to be offset | |
FBStoryFolder | ParentFolder |
Read Only Property: Parent folder. | |
FBStoryTrack | ParentTrack |
Read Only Property: Parent track, if the track is of Character or Animation type. | |
bool | PassThrough |
Read Write Property: Enable passthrough of animation if there is no clip on track animation is taken from other tracks of take | |
str | RecordClipPath |
Read Write Property: Path for story recording. Can be relative or full path. | |
bool | RecordTrack |
Read Write Property: Path for story recording. Can be relative or full path. | |
FBStoryTrackRefMode | ReferenceMode |
Read Write Property: Track composition mode, kFBStoryTrackOverride or kFBStoryTrackAdditive | |
bool | ShowBackplate |
Read Write Property: If true, the backplate will be shown. | |
bool | ShowFrontplate |
Read Write Property: If true, the frontplate will be shown. | |
bool | Solo |
Read Write Property: If true, this track will be the only one to play. | |
FBListStorySubTrack | SubTracks |
List: Only Character and Animation tracks can have sub-tracks. | |
FBVideo | TrackVideo |
Read Only Property: This FBVideo can be used as a texture. | |
FBStoryTrackType | Type |
Read Only Property: Type of the track | |
FBAnimatableDouble | Weight |
Read Write Property: Control the blend amount. | |
![]() | |
bool | Active |
Read Write Property: Active state. | |
bool | Deformer |
Read Write Property: Is a deformer constraint? | |
str | Description |
Read Write Property: Long description of constraint. | |
bool | HasLayout |
Read Write Property: Does the constraint have a layout? | |
bool | Lock |
Read Write Property: Lock state. | |
FBAction | Snap |
Function Property: Snap constraint. | |
FBAnimatableDouble | Weight |
Read Write Property: Weight of constraint. | |
![]() | |
bool | Animatable |
Read Write Property: Is the box animatable. | |
bool | Live |
Read Write Property: Is live? | |
bool | RecordMode |
Read Write Property: Is recording? | |
str | UniqueName |
internal Unique name. | |
![]() | |
FBListComponent | Components |
List: List of components. | |
str | LongName |
Read Write Property: Name and namespace for object. | |
str | Name |
Read Write Property: Unique name of object. See sample: RemoveSuffixFromNameOfSceneElements.py. | |
FBListComponent | Parents |
List: Parents. | |
FBManager | PropertyList |
Read Only Property: Manages all of the properties for the component. | |
bool | Selected |
Read Write Property: Selected property. | |
int | TypeInfo |
Contains the Type information of the object. | |
![]() | |
str | ClassGroupName |
ClassGroupName of the object. | |
int | TypeInfo |
TypeInfo. | |
Story Track class.
Tracks are containers for clips (medias), have a specific type which offer different functions. Note: To change the travelling node of a track, search for the "TravellingNode" property on the track and then connect/disconnect the appropriate object. Python example: lPropTravellingNode = lAnimTrack.PropertyList.Find("TravellingNode") lCube.ConnectDst(lPropTravellingNode)
See samples: CreateShotClip.py, AudioTrackSetupTool.py, BloopSlate.py, RecordLight.py, FBStoryFolder.py, VideoClip.py, PlotNonSelectedCharStoryTracks.py, PlotSelectedCharStoryTracks.py, PrintClipNamesAndStartStopFrames.py.
FBStoryTrack | ( | FBStoryTrackType | pTrackType, |
FBStoryFolder | pFolder = None |
||
) |
Constructor.
pTrackType | Type of the track to be created. |
pFolder | If NULL, parent will be the global root folder. |
FBStoryTrack | ( | FBComponent | pSource, |
FBStoryFolder | pFolder = None |
||
) |
Constructor.
pSource | Source of the track to be created based on media component type. |
pFolder | If NULL, parent will be the global root folder. |
AddClip | ( | FBComponent | pClip, |
FBTime | pTime | ||
) |
AddClip Add the clip to the track.
ChangeDetailsBegin | ( | ) |
ChangeDetailsBegin.
You must call this function before adding/removing any object to the Details list or it won't work.
ChangeDetailsEnd | ( | ) |
ChangeDetailsEnd.
You must call this function after adding/removing any object to the Details list or it won't work.
FBStoryClip CopyTakeIntoTrack | ( | FBTimeSpan | pTimeSpan, |
FBTake | pTake, | ||
bool | pConnectToCurrentTake, | ||
FBTime | pOutputOffset = FBTime(0) , |
||
bool | pMakeUndoable = False |
||
) |
CopyTakeIntoTrack Copy animation from the specified take for affected objects of the track.
pTimeSpan | Time span for the clip to create. |
pTake | Take to get the animation from. |
pConnectToCurrentTake | True to connect the created clip to the current take, false otherwise. |
pOutputOffset | Time offset for the clip if necessary. |
pMakeUndoable | If the operation should be undoable. |
FBStoryClip CopyTakeIntoTrack | ( | FBTimeSpan | pTimeSpan, |
FBTake | pTake, | ||
FBTime | pOutputOffset = 0 , |
||
bool | pMakeUndoable = False |
||
) |
CopyTakeIntoTrack Copy animation from the specified take for affected objects of the track.
This method will always connect the created clip to the current take.
pTimeSpan | Time span for the clip to create. |
pTake | Take to get the animation from. |
pOutputOffset | Time offset for the clip if necessary. |
pMakeUndoable | If the operation should be undoable. |
FBStoryTrack CreateSubTrack | ( | FBStoryTrackType | pTrackType, |
FBStoryTrackRefMode | pRefMode | ||
) |
Create a sub track, Only Character and Animation tracks can have sub-tracks.
pTrackType | Type of the sub track to be created. |
pRefMode | Composition mode of the sub track, kFBStoryTrackOverride or kFBStoryTrackAdditive. |
EnableBodyPart | ( | FBStoryTrackBodyPart | pPart, |
bool | pEnable | ||
) |
EnableBodyPart.
pPart | Which part to enable/disable. |
pEnable | If True, this will enable the body part solving while false will disable it. Enable a specific body part for character solving. |
FBDelete | ( | ) |
Virtual FBDelete function.
bool IsBodyPartEnabled | ( | FBStoryTrackBodyPart | pPart | ) |
IsBodyPartEnabled.
Is a specific body part is enabled.
Load | ( | bool | pLoad | ) |
Allow to load/unload all story clips under this track.
PlotToCameraSwitcher Plot the Shot Track to the Camera Switcher on the given Take.
This undoable operation will overwrite the Camera Switcher of Take.
pTake | Take to plot the Shot Track to the Camera Switcher to. |
bool AcceptKey |
Read Write Property: Allow track to accept keys
int AudioOutIndex |
Read Write Property: Audio Output's index to use.
FBCharacter Character |
Read Write Property: Character to use.
int CharacterIndex |
Read Write Property: Character's index to use.
str ClipNameConvention |
Read Write Property: Naming convention for each new recording clip that is created. Can use special tags: <Name> <StartTCValue> <StartFrameValue> <StartDate> <StartTime> <TakeName>
FBListStoryClip Clips |
List: Clips contained in this track.
FBListStoryDetails Details |
List: All objects associated to this track for processing.
bool Ghost |
Read Write Property: Show ghosts
bool GhostModel |
Read Write Property: Show ghost of models
bool GhostPivot |
Read Write Property: Show ghost of match object
FBStoryTrackGhostShowMode GhostShowTrackMode |
Read Write Property: Show the ghosts for all the clips or only the adjacent clips. See FBStoryTrackGhostShowMode
bool GhostTravelling |
Read Write Property: Show ghost of clip vector or traveling node
str Label |
Read Write Property: Label to display for this story track.
bool Mute |
Read Write Property: If true, this track wont' play.
bool OffsetEnable |
Read Write Property: When enabled, allow clip to be offset
FBStoryFolder ParentFolder |
Read Only Property: Parent folder.
FBStoryTrack ParentTrack |
Read Only Property: Parent track, if the track is of Character or Animation type.
bool PassThrough |
Read Write Property: Enable passthrough of animation if there is no clip on track animation is taken from other tracks of take
str RecordClipPath |
Read Write Property: Path for story recording. Can be relative or full path.
bool RecordTrack |
Read Write Property: Path for story recording. Can be relative or full path.
FBStoryTrackRefMode ReferenceMode |
Read Write Property: Track composition mode, kFBStoryTrackOverride or kFBStoryTrackAdditive
bool ShowBackplate |
Read Write Property: If true, the backplate will be shown.
bool ShowFrontplate |
Read Write Property: If true, the frontplate will be shown.
bool Solo |
Read Write Property: If true, this track will be the only one to play.
FBListStorySubTrack SubTracks |
List: Only Character and Animation tracks can have sub-tracks.
FBStoryTrackType Type |
Read Only Property: Type of the track
FBAnimatableDouble Weight |
Read Write Property: Control the blend amount.
