FBVisualComponent Class Reference

Visual Component base class. More...

#include <pyfbsdk.h>

Inheritance diagram for FBVisualComponent:

Public Member Functions

 FBVisualComponent ()
 Constructor.

bool AddChild (FBVisualComponent pChild, int pId=0)
 Add a child component.

FBVisualComponent GetChild (int pId=0)
 Get a child component.

QWidget GetQWidgetAddress ()
 Get internal QWidget.

bool IsView ()
 Is component a view?

 Refresh (bool pNow=False)
 Refresh component.

 ViewExpose ()
 Exposed view callback function.

 ViewInput (int pMouseX, int pMouseY, FBInputType pAction, int pButtonKey, int pModifier)
 Input callback function.

- Public Member Functions inherited from FBComponent
 FBComponent ()
 Constructor.

str ClassName ()
 Get the class name.

 DisableObjectFlags (FBObjectFlag pFlags)
 Disable a specific Object Flags.

 EnableObjectFlags (FBObjectFlag pFlags)
 Enable a specific Object Flags.

bool FBCreate ()
 Open Reality Creation function.

 FBDelete ()
 Open Reality deletion function.

 FBDestroy ()
 Open Reality destruction function.

FBObjectFlag GetObjectFlags ()
 Get all Object Flags (concatenated).

bool GetObjectStatus (FBObjectStatus pStatus)
 Check to see if an object status is enabled.

FBFileReference GetOwnerFileReference (p0)
 Get the owner FileReference object.

 HardSelect ()
 HardSelect.

bool HasObjectFlags (FBObjectFlag pFlags)
 Check whether a specific object flag is enabled.

bool Is (int pTypeId)
 Returns true if object is of type TypeId.

bool ProcessNamespaceHierarchy (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True)
 ProcessNamespaceHierarchy.

bool ProcessObjectNamespace (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True)
 ProcessObjectNamespace.

int PropertyAdd (FBProperty pProperty)
 Add a property to the component's property manager.

bool PropertyAddReferenceProperty (FBProperty pReferenceProperty)
 Add a reference property to the component's property manager.

FBProperty PropertyCreate (str pName, FBType pType, str pDataType, bool pAnimatable, bool pIsUser=False, FBProperty pReferenceSource=None)
 Create user or dynamic property.

 PropertyGetModifiedList (FBArrayTemplate< FB > pPropList, FBPlugModificationFlag pModificationFlags)
 Get list of properties which have been modified since last loading.

 PropertyRemove (FBProperty pProperty)
 Remove a Property from the component's Property manager.

 SetObjectFlags (FBObjectFlag pFlags)
 SetObjectFlags.

 SetObjectStatus (FBObjectStatus pStatus, bool pValue)
 Enable/Disable a specific Object Status.


Public Attributes

str RegionName
 Read Write Property: Region name.

int RegionOffsetX
 Read Write Property: Region X offset.

int RegionOffsetY
 Read Write Property: Region Y offset.

int RegionOffsetWidth
 Read Write Property: Region width offset.

int RegionOffsetHeight
 Read Write Property: Region height offset.

float RegionRatioX
 Read Write Property: Ratio for X attachment.

float RegionRatioY
 Read Write Property: Ratio for Y attachment.

float RegionRatioWidth
 Read Write Property: Ratio for Width attachment.

float RegionRatioHeight
 Read Write Property: Ratio for Height attachment.


FBAttachType RegionAttachTypeX
 Read Write Property: X Attachment type.

FBAttachType RegionAttachTypeY
 Read Write Property: Y Attachment type.

FBAttachType RegionAttachTypeWidth
 Read Write Property: Width Attachment type.

FBAttachType RegionAttachTypeHeight
 Read Write Property: Height Attachment type.

FBVisualComponent RegionAttachToX
 Read Write Property X Attachment source.

FBVisualComponent RegionAttachToY
 Read Write Property: Y Attachment source.

FBVisualComponent RegionAttachToWidth
 Read Write Property: Width Attachment source.

FBVisualComponent RegionAttachToHeight
 Read Write Property: Height Attachment source.


int RegionPosMaxX
 Read Write Property: Region X position Max

int RegionPosMinX
 Read Write Property: Region X position Min

int RegionPosMaxY
 Read Write Property: Region Y position Max

int RegionPosMinY
 Read Write Property: Region Y position Min

str BorderCaption
 Read Write Property: Caption to display in border.

bool BorderShowCaption
 Read Write Property: Show caption?

FBBorderStyle BorderStyle
 Read Write Property: Style of border.

bool BorderInSet
 Read Write Property: Is border inset?

int BorderWidth
 Read Write Property: Width of border.

int BorderSpacing
 Read Write Property: Spacing of border.

float BorderMaxAngle
 Read Write Property: Max angle for rounding.

int BorderCornerRadius
 Read Write Property: Corner radius (rounded).


str Caption
 Property: Widget caption.


bool Enabled
 Read Write Property: Is visual enabled?


int Height
 Read Write Property: Height.


str Hint
 Read Write Property: Hint to show.


int Left
 Read Write Property: Left coordinate.


bool ReadOnly
 Read Write Property: Is visual component read only?


int Top
 Read Write Property: Top coordinate.


bool Visible
 Read Write Property: Is visual component visible?


int Width
 Read Write Property: Width.


- Public Attributes inherited from FBComponent
FBListComponent Components
 List: List of components.


str LongName
 Read Write Property: Name and namespace for object.


str Name
 Read Write Property: Unique name of object. See sample: RemoveSuffixFromNameOfSceneElements.py.

FBListComponent Parents
 List: Parents.


FBManager PropertyList
 Read Only Property: Manages all of the properties for the component.


bool Selected
 Read Write Property: Selected property.


int TypeInfo
 Contains the Type information of the object.


- Public Attributes inherited from FBPlug
str ClassGroupName
 ClassGroupName of the object.


int TypeInfo
 TypeInfo.



Detailed Description

Visual Component base class.


All of the user interface elements available in the SDK derive from this class.

Constructor & Destructor Documentation

◆ FBVisualComponent()

Constructor.

Member Function Documentation

◆ AddChild()

bool AddChild ( FBVisualComponent  pChild,
int  pId = 0
)

Add a child component.

Parameters
pChildVisual component to add as a child.
pIdUser reference number to associate with pChild(default=0).
Returns
Operation was successful (true or false).

◆ GetChild()

FBVisualComponent GetChild ( int  pId = 0)

Get a child component.

Parameters
pIdUser reference number to look for child with(default=0).
Returns
Handle to child (NULL if not found).

◆ GetQWidgetAddress()

QWidget GetQWidgetAddress ( )

Get internal QWidget.

Returns
Handle to internal QWidget object.

◆ IsView()

bool IsView ( )

Is component a view?

Returns
true if component is a view.

◆ Refresh()

Refresh ( bool  pNow = False)

Refresh component.

Parameters
pNowRefresh immediately if true (default = false).

◆ ViewExpose()

ViewExpose ( )

Exposed view callback function.

◆ ViewInput()

ViewInput ( int  pMouseX,
int  pMouseY,
FBInputType  pAction,
int  pButtonKey,
int  pModifier
)

Input callback function.

Parameters
pMouseXMouse X position.
pMouseYMouse Y position.
pActionMouse action.
pButtonKeyKeyboard input.
pModifierKeyboard input modifier.

Member Data Documentation

◆ BorderCaption

str BorderCaption

Read Write Property: Caption to display in border.

◆ BorderCornerRadius

int BorderCornerRadius

Read Write Property: Corner radius (rounded).

◆ BorderInSet

bool BorderInSet

Read Write Property: Is border inset?

◆ BorderMaxAngle

float BorderMaxAngle

Read Write Property: Max angle for rounding.

◆ BorderShowCaption

bool BorderShowCaption

Read Write Property: Show caption?

◆ BorderSpacing

int BorderSpacing

Read Write Property: Spacing of border.

◆ BorderStyle

FBBorderStyle BorderStyle

Read Write Property: Style of border.

◆ BorderWidth

int BorderWidth

Read Write Property: Width of border.

◆ Caption

str Caption

Property: Widget caption.

◆ Enabled

bool Enabled

Read Write Property: Is visual enabled?

◆ Height

int Height

Read Write Property: Height.

◆ Hint

str Hint

Read Write Property: Hint to show.

◆ Left

int Left

Read Write Property: Left coordinate.

◆ ReadOnly

bool ReadOnly

Read Write Property: Is visual component read only?

◆ RegionAttachToHeight

FBVisualComponent RegionAttachToHeight

Read Write Property: Height Attachment source.

◆ RegionAttachToWidth

FBVisualComponent RegionAttachToWidth

Read Write Property: Width Attachment source.

◆ RegionAttachToX

FBVisualComponent RegionAttachToX

Read Write Property X Attachment source.

◆ RegionAttachToY

FBVisualComponent RegionAttachToY

Read Write Property: Y Attachment source.

◆ RegionAttachTypeHeight

FBAttachType RegionAttachTypeHeight

Read Write Property: Height Attachment type.

◆ RegionAttachTypeWidth

FBAttachType RegionAttachTypeWidth

Read Write Property: Width Attachment type.

◆ RegionAttachTypeX

FBAttachType RegionAttachTypeX

Read Write Property: X Attachment type.

◆ RegionAttachTypeY

FBAttachType RegionAttachTypeY

Read Write Property: Y Attachment type.

◆ RegionName

str RegionName

Read Write Property: Region name.

◆ RegionOffsetHeight

int RegionOffsetHeight

Read Write Property: Region height offset.

◆ RegionOffsetWidth

int RegionOffsetWidth

Read Write Property: Region width offset.

◆ RegionOffsetX

int RegionOffsetX

Read Write Property: Region X offset.

◆ RegionOffsetY

int RegionOffsetY

Read Write Property: Region Y offset.

◆ RegionPosMaxX

int RegionPosMaxX

Read Write Property: Region X position Max

◆ RegionPosMaxY

int RegionPosMaxY

Read Write Property: Region Y position Max

◆ RegionPosMinX

int RegionPosMinX

Read Write Property: Region X position Min

◆ RegionPosMinY

int RegionPosMinY

Read Write Property: Region Y position Min

◆ RegionRatioHeight

float RegionRatioHeight

Read Write Property: Ratio for Height attachment.

◆ RegionRatioWidth

float RegionRatioWidth

Read Write Property: Ratio for Width attachment.

◆ RegionRatioX

float RegionRatioX

Read Write Property: Ratio for X attachment.

◆ RegionRatioY

float RegionRatioY

Read Write Property: Ratio for Y attachment.

◆ Top

int Top

Read Write Property: Top coordinate.

◆ Visible

bool Visible

Read Write Property: Is visual component visible?

◆ Width

int Width

Read Write Property: Width.
