In this tutorial, we step through the meshing of the vice grips model shown in the following image. We add a joint at the holes to allow the parts to rotate. This model is used in the Vice Grips Static Stress Analysis tutorial.
Features Illustrated:
- Solid meshing
- Adding joints
Goals
- Import and mesh a universal CAD format model.
- Create a pin-joint between the holes in the two parts.
