The Drainage Tool is a completely unique solution that has been developed to streamline the previously arduous task of drawing accurate Public Health systems. The complexity of angles and falls in Public Health design make it very difficult to calculate invert levels and the positions of the correct connection into the vertical stacks. Now, using the powerful drainage tools, users can calculate angles and falls easily and quickly transform a blank drawing into a full BIM 3D model that can be used for estimating, value engineering and co-ordination.
Supported by comprehensive 'real-world' fitting libraries, will enable co-ordinator to draw highly accurate BIM-Rich service models in a fraction of the standard time. The majority of a users time will be spent on line drawing for any drainage model. Once the lines are all drawn, all that remains is to choose a desired fall gradient and to specify which point on the system will be fixed at the desired elevation. The final point - one single click and the users fully functional drainage system is produced.
