| FBHUDRectElement (str pName) |
| Constructor.
|
|
| FBBox (str pName) |
| Constructor.
|
|
bool | AnimationNodeDestroy (FBAnimationNode pAnimationNode) |
| Destroy an animation node.
|
|
FBAnimationNode | AnimationNodeInGet () |
| Get the (IN/OUT) animation node for this box.
|
|
bool | AnimationNodeIsUserData (FBAnimationNode pAnimationNode) |
| Is the animation node user data?
|
|
FBAnimationNode | AnimationNodeOutGet () |
|
str | FbxGetObjectSubType () |
| Returns the class sub type inherited by the class of an object, for example: 'Relations', 'Parent-Child', 'Number to Vector', 'Shot'.
|
|
str | FbxGetObjectType () |
| Returns the class type inherited by the class of an object, for example: 'Box', 'Constraint', 'TimelineXTrack'.
|
|
FBAnimationNode | GetInConnector (int pIndex) |
| Get the animation node input associated with the given index.
|
|
int | GetInConnectorCount () |
| Get the number of animation node inputs for this box.
|
|
FBAnimationNode | GetOutConnector (int pIndex) |
| Get the animation node output associated with the given index.
|
|
int | GetOutConnectorCount () |
| Get the number of animation node outputs for this box.
|
|
| FBComponent () |
| Constructor.
|
|
str | ClassName () |
| Get the class name.
|
|
| DisableObjectFlags (FBObjectFlag pFlags) |
| Disable a specific Object Flags.
|
|
| EnableObjectFlags (FBObjectFlag pFlags) |
| Enable a specific Object Flags.
|
|
bool | FBCreate () |
| Open Reality Creation function.
|
|
| FBDelete () |
| Open Reality deletion function.
|
|
| FBDestroy () |
| Open Reality destruction function.
|
|
FBObjectFlag | GetObjectFlags () |
| Get all Object Flags (concatenated).
|
|
bool | GetObjectStatus (FBObjectStatus pStatus) |
| Check to see if an object status is enabled.
|
|
FBFileReference | GetOwnerFileReference (p0) |
| Get the owner FileReference object.
|
|
| HardSelect () |
| HardSelect.
|
|
bool | HasObjectFlags (FBObjectFlag pFlags) |
| Check whether a specific object flag is enabled.
|
|
bool | Is (int pTypeId) |
| Returns true if object is of type TypeId.
|
|
bool | ProcessNamespaceHierarchy (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True) |
| ProcessNamespaceHierarchy.
|
|
bool | ProcessObjectNamespace (FBNamespaceAction pNamespaceAction, str pNamespaceName, str pReplaceTo=None, bool pAddRight=True) |
| ProcessObjectNamespace.
|
|
int | PropertyAdd (FBProperty pProperty) |
| Add a property to the component's property manager.
|
|
bool | PropertyAddReferenceProperty (FBProperty pReferenceProperty) |
| Add a reference property to the component's property manager.
|
|
FBProperty | PropertyCreate (str pName, FBType pType, str pDataType, bool pAnimatable, bool pIsUser=False, FBProperty pReferenceSource=None) |
| Create user or dynamic property.
|
|
| PropertyGetModifiedList (FBArrayTemplate< FB > pPropList, FBPlugModificationFlag pModificationFlags) |
| Get list of properties which have been modified since last loading.
|
|
| PropertyRemove (FBProperty pProperty) |
| Remove a Property from the component's Property manager.
|
|
| SetObjectFlags (FBObjectFlag pFlags) |
| SetObjectFlags.
|
|
| SetObjectStatus (FBObjectStatus pStatus, bool pValue) |
| Enable/Disable a specific Object Status.
|
|
|
FBColorAndAlpha | Color |
| Read Write Property: Color of the rectangluar region.
|
|
float | Height |
| Read Write Property: Specifies the height of HUD element on the screen. It's in pixel when ScaleByPercent is false and percentage when ScaleByPercent is true.
|
|
FBHUDElementHAlignment | HorizontalDock |
| Read Write Property: Specifies if the HUD element will be horizontally docked to the Left, Right, or Center.
|
|
FBHUDElementHAlignment | Justification |
| Read Write Property: Specifies if the justification of the HUD element is Left, Right, or Center.
|
|
bool | PositionByPercent |
| Read Write Property: When set to true, X and Y position values are in percentage, relative to the corresponding camera view dimension. Otherwise, they are absolute pixel values.
|
|
bool | ScaleByPercent |
| Read Write Property: When set to true, Scale is in percentage, relative to the corresponding camera view dimension. Otherwise, it is an absolute value.
|
|
bool | ScaleUniformly |
| Read Write Property: Specifies whether the width and height of HUD element will be scaled uniformly according to the initial aspect ratio.
|
|
bool | Show |
| Read Write Property: Specifies if the HUD element will be displayed or not.
|
|
FBHUDElementVAlignment | VerticalDock |
| Read Write Property: Specifies if the HUD element will be vertically docked to the Bottom, Top, or Center.
|
|
float | Width |
| Read Write Property: Specifies the width of HUD element on the screen. It's in pixel when ScaleByPercent is false and percentage when ScaleByPercent is true.
|
|
float | X |
| Read Write Property: Specifies the horizontal position of the HUD element, relative to dock position and justification.
|
|
float | Y |
| Read Write Property: Specifies the vertical position of the HUD element, relative to dock position and justification.
|
|
bool | Animatable |
| Read Write Property: Is the box animatable.
|
|
bool | Live |
| Read Write Property: Is live?
|
|
bool | RecordMode |
| Read Write Property: Is recording?
|
|
str | UniqueName |
| internal Unique name.
|
|
FBListComponent | Components |
| List: List of components.
|
|
str | LongName |
| Read Write Property: Name and namespace for object.
|
|
str | Name |
| Read Write Property: Unique name of object. See sample: RemoveSuffixFromNameOfSceneElements.py.
|
|
FBListComponent | Parents |
| List: Parents.
|
|
FBManager | PropertyList |
| Read Only Property: Manages all of the properties for the component.
|
|
bool | Selected |
| Read Write Property: Selected property.
|
|
int | TypeInfo |
| Contains the Type information of the object.
|
|
str | ClassGroupName |
| ClassGroupName of the object.
|
|
int | TypeInfo |
| TypeInfo.
|
|
Heads Up display.
Rectangle HUD element.
See sample: HUDElements.py.
