Add a Note Block to a Sheet

A note block (also called an annotation schedule) is a list of construction notes for a drawing. You can create a note block and place it on a sheet to document the building model.

You can also document a building model using keynote legends. See Add a legend to a sheet.

To add a note block to a sheet

1. In the project, create the project view to annotate.
2. Add notes to the view, and create the note block.
3. Add a sheet.

   See Add a sheet.

4. Place the note block on the sheet, as follows:
   1. In the Project Browser, expand Schedules/Quantities.
   2. Select the name of the note block, drag it onto the sheet, and click to place it.
