FBComponent Class Reference

#include <mobu-python-api.h>

Class Description

MotionBuilder SDK base class.

FBComponent defines common object characteristics, including creation and destruction methods. It is used to encapsulate internal application objects so they can be exposed to the SDK. It is also used as the base class to encapsulate objects with FBProperty data members and provides a scheme for property management. You cannot instantiate FBProperty objects. To reference a property, use an instance of an FBComponent object. The methods FBComponent::PropertyCreate and FBComponent::PropertyRemove can be used to modify an object's properties. Basic operators are overloaded in FBComponent. The constructor and destructor are created and defined with macros in the header files. Objects inheriting from FBComponent must define FBComponent::FBCreate(), and FBComponent::FBDestroy(). All memory management issues for the component should also be addressed here. Destroy an object with FBDelete(). The code sample FBComponent.py shows how to get a handle on a scene object via its name.

See the C++ reference

Inheritance diagram for FBComponent:

Public Member Functions
	__reduce__ ()
FBPropertyList	PropertyGetModifiedList (FBComponent arg1, FBPlugModificationFlag arg2)
	Get list of properties which have been modified since last loading. More...
str	ClassName (FBComponent arg1)
	Get the class name. More...
	DisableObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	Disable a specific Object Flags. More...
	EnableObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	Enable a specific Object Flags. More...
bool	FBCreate (FBComponent arg1)
	Open Reality Creation function. More...
	FBDelete (FBComponent arg1)
	Open Reality deletion function. More...
	FBDestroy (FBComponent arg1)
	Open Reality destruction function. More...
FBObjectFlag	GetObjectFlags (FBComponent arg1)
	Get all Object Flags (concatenated). More...
bool	GetObjectStatus (FBComponent arg1, FBObjectStatus arg2)
	Check to see if an object status is enabled. More...
bool	HasObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	Check whether a specific object flag is enabled. More...
bool	Is (FBComponent arg1, object arg2)
	Returns true if object is of type TypeId. More...
bool	ProcessNamespaceHierarchy (FBComponent arg1, FBNamespaceAction arg2, str arg3, str arg4, object arg5)
	ProcessNamespaceHierarchy. More...
bool	ProcessObjectNamespace (FBComponent arg1, FBNamespaceAction arg2, str arg3, str arg4, object arg5)
	ProcessObjectNamespace. More...
int	PropertyAdd (FBComponent arg1, FBProperty arg2)
	Add a property to the component's property manager. More...
bool	PropertyAddReferenceProperty (FBComponent arg1, FBProperty arg2)
	Add a reference property to the component's property manager. More...
object	PropertyCreate (FBComponent arg1, str arg2, FBPropertyType arg3, str arg4, object arg5, object arg6, FBProperty arg7)
	Create user or dynamic property. More...
	PropertyRemove (FBComponent arg1, FBProperty arg2)
	Remove a Property from the component's Property manager. More...
	SetObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	SetObjectFlags. More...
	SetObjectStatus (FBComponent arg1, FBObjectStatus arg2, object arg3)
	Enable/Disable a specific Object Status. More...
	HardSelect (FBComponent arg1)
	HardSelect. More...
object	GetOwnerFileReference (FBComponent arg1)
	Get the owner FileReference object. More...
	__init__ (...)
	Constructor. More...
Public Member Functions inherited from FBPlug
	__reduce__ ()
bool	BeginChange (FBPlug arg1)
	Begins a change on multiple plugs. More...
str	ClassName (FBPlug arg1)
	internal System vars. More...
bool	ConnectDst (FBPlug arg1, FBPlug arg2, FBConnectionType arg3)
	Add a destination connection. More...
bool	ConnectDstAt (FBPlug arg1, object arg2, FBPlug arg3, FBConnectionType arg4)
	Add a destination connection. More...
bool	ConnectSrc (FBPlug arg1, FBPlug arg2, FBConnectionType arg3)
	Add a source connection. More...
bool	ConnectSrcAt (FBPlug arg1, object arg2, FBPlug arg3, FBConnectionType arg4)
	Add a source connection. More...
	DisconnectAllDst (FBPlug arg1)
	Remove all destination connections. More...
	DisconnectAllSrc (FBPlug arg1)
	Remove all source connections. More...
bool	DisconnectDst (FBPlug arg1, FBPlug arg2)
	Remove a destination connection. More...
bool	DisconnectDstAt (FBPlug arg1, object arg2)
	Remove a destination connection at a specified index. More...
bool	DisconnectSrc (FBPlug arg1, FBPlug arg2)
	Remove a source connection. More...
bool	DisconnectSrcAt (FBPlug arg1, object arg2)
	Remove a source connection at a specified index. More...
	EndChange (FBPlug arg1)
	Ends a change on multiple plugs. More...
object	GetDst (FBPlug arg1, object arg2)
	Get a destination connection's plug at specified index. More...
int	GetDstCount (FBPlug arg1)
	Get destination connection count. More...
FBConnectionType	GetDstType (FBPlug arg1, object arg2)
	Get a destination connection's type at specified index. More...
object	GetOwned (FBPlug arg1, object arg2)
	Get the owned plug at specified index. More...
int	GetOwnedCount (FBPlug arg1)
	Get the owned plug count. More...
object	GetOwner (FBPlug arg1)
	Get the owner of this plug. More...
object	GetSrc (FBPlug arg1, object arg2)
	Get a source connection's plug at specified index. More...
int	GetSrcCount (FBPlug arg1)
	Get source connection count. More...
FBConnectionType	GetSrcType (FBPlug arg1, object arg2)
	Get a source connection's type at specified index. More...
bool	Is (FBPlug arg1, object arg2)
	Is( int pTypeId ) More...
bool	IsSDKComponent (FBPlug arg1)
	Return whether or not item is an SDK component. More...
	MoveSrcAt (...)
bool	ReplaceDstAt (FBPlug arg1, object arg2, FBPlug arg3)
	Replace a destination connection at a specified index. More...
bool	ReplaceSrcAt (FBPlug arg1, object arg2, FBPlug arg3)
	Replace a source connection at a specified index. More...
bool	SwapSrc (FBPlug arg1, object arg2, object arg3)
	Swap source connection at index A with source connection at index B. More...
	SetSelfModified (FBPlug arg1, FBPlugModificationFlag arg2, object arg3)
	Set the plug's self modification flag. More...
bool	GetSelfModified (FBPlug arg1, FBPlugModificationFlag arg2)
	Tell if the plug's self has changed. More...
	SetContentModified (FBPlug arg1, FBPlugModificationFlag arg2, object arg3)
	Set the plug's owned property/object's modification flag. More...
bool	GetContentModified (FBPlug arg1, FBPlugModificationFlag arg2)
	Tell if the plug's content has changed. More...
int	GetPlugConnectionModifiedList (FBPlug arg1, FBPlugList arg2, FBPlugModificationFlag arg3, object arg4)
	Get plug's modified src/dst property/object connection added/removed List. More...
bool	RevertModification (FBPlug arg1, FBPlugModificationFlag arg2)
	Revert the plug's modification to original status. More...
	__init__ (...)
method	staticmethod (function)
Public Member Functions inherited from FBPythonWrapper
	__reduce__ ()
	__init__ (...)

Public Attributes
object	OwnerNamespace
ORSDK2018::FBPropertyListComponent	Components
	List: List of components. More...
ORSDK2018::FBPropertyString	Name
	Read Write Property: Unique name of object. More...
ORSDK2018::FBPropertyString	LongName
	Read Write Property: Name and namespace for object. More...
object	FullName
ORSDK2018::FBPropertyListComponent	Parents
	List: Parents. More...
ORSDK2018::FBPropertyManager	PropertyList
	Read Only Property: Manages all of the properties for the component. More...
FBPropertyBool	Selected
	Read Write Property: Selected property. More...
Public Attributes inherited from FBPythonWrapper
object	OnUnbind

Member Function Documentation

__init__

(

...

)

Constructor.

Python Docstring:

Raises an exception
This class cannot be instantiated from Python

C++ Signature:

 FBComponent(HIObject pObject)

Parameters

pObject

Object to copy component from (default is NULL).

See the C++ reference

__reduce__

(

)

str ClassName

(

FBComponent

arg1

)

Get the class name.

Python Docstring:

ClassName( (FBComponent)arg1) -> str

C++ Signature:

const char * ClassName()

Returns

The class name (i.e. "FBComponent").

See the C++ reference

DisableObjectFlags	(	FBComponent	arg1,
		FBObjectFlag	arg2
	)

Disable a specific Object Flags.

Python Docstring:

DisableObjectFlags( (FBComponent)arg1, (FBObjectFlag)arg2) -> None

C++ Signature:

void DisableObjectFlags(FBObjectFlag pFlags)

Parameters

pFlags

Flags to disable.

See the C++ reference

EnableObjectFlags	(	FBComponent	arg1,
		FBObjectFlag	arg2
	)

Enable a specific Object Flags.

Python Docstring:

EnableObjectFlags( (FBComponent)arg1, (FBObjectFlag)arg2) -> None

C++ Signature:

void EnableObjectFlags(FBObjectFlag pFlags)

Parameters

pFlags

Flags to enable.

See the C++ reference

bool FBCreate

(

FBComponent

arg1

)

Open Reality Creation function.

Python Docstring:

FBCreate( (FBComponent)arg1) -> bool

C++ Signature:

bool FBCreate()

Returns

Outcome of creation (true/false).

See the C++ reference

FBDelete

(

FBComponent

arg1

)

Open Reality deletion function.

Python Docstring:

FBDelete( (FBComponent)arg1) -> None

C++ Signature:

void FBDelete()

See the C++ reference

FBDestroy

(

FBComponent

arg1

)

Open Reality destruction function.

Python Docstring:

FBDestroy( (FBComponent)arg1) -> None

C++ Signature:

void FBDestroy()

See the C++ reference

FBObjectFlag GetObjectFlags

(

FBComponent

arg1

)

Get all Object Flags (concatenated).

Python Docstring:

GetObjectFlags( (FBComponent)arg1) -> FBObjectFlag

C++ Signature:

FBObjectFlag GetObjectFlags()

Returns

Get all object flags in one call. Flags can be concatenated.

See the C++ reference

bool GetObjectStatus	(	FBComponent	arg1,
		FBObjectStatus	arg2
	)

Check to see if an object status is enabled.

Python Docstring:

GetObjectStatus( (FBComponent)arg1, (FBObjectStatus)arg2) -> bool

C++ Signature:

bool GetObjectStatus(FBObjectStatus pStatus)

Parameters

pStatus

Status to query.

See the C++ reference

object GetOwnerFileReference

(

FBComponent

arg1

)

Get the owner FileReference object.

Python Docstring:

GetOwnerFileReference( (FBComponent)arg1) -> object

C++ Signature:

ORSDK2018::FBFileReference * GetOwnerFileReference(void )

Returns

the owner FileReference object

See the C++ reference

HardSelect

(

FBComponent

arg1

)

HardSelect.

Python Docstring:

HardSelect( (FBComponent)arg1) -> None

C++ Signature:

void HardSelect()

Selects the object, and emits a hard select event for UI update notification.

See the C++ reference

bool HasObjectFlags	(	FBComponent	arg1,
		FBObjectFlag	arg2
	)

Check whether a specific object flag is enabled.

Python Docstring:

HasObjectFlags( (FBComponent)arg1, (FBObjectFlag)arg2) -> bool

C++ Signature:

bool HasObjectFlags(FBObjectFlag pFlags)

Parameters

pFlags

Flags to check if they are present.

Returns

True if all flags in pFlags are enabled.

See the C++ reference

bool Is	(	FBComponent	arg1,
		object	arg2
	)

Returns true if object is of type TypeId.

Python Docstring:

Is( (FBComponent)arg1, (object)arg2) -> bool

C++ Signature:

bool Is(int pTypeId)

Parameters

pTypeId

TypeId to compare object to.

Returns

Result of the comparison.

See the C++ reference

bool ProcessNamespaceHierarchy	(	FBComponent	arg1,
		FBNamespaceAction	arg2,
		str	arg3,
		str	arg4,
		object	arg5
	)

ProcessNamespaceHierarchy.

Python Docstring:

ProcessNamespaceHierarchy( (FBComponent)arg1, (FBNamespaceAction)arg2, (str)arg3 [, (str)arg4 [, (object)arg5]]) -> bool

C++ Signature:

bool ProcessNamespaceHierarchy(FBNamespaceAction pNamespaceAction, const char * pNamespaceName, const char * pReplaceTo = ((void *) 0), bool pAddRight = true)

New Namespace name should only contains alphabet, digit and '_', Can't start with digit. This recursive function goes through the whole hierarchy (children) to add/replace the prefix. If you need to work on a single object, use the ProcessObjectPrefix function.

Parameters

pNamespaceAction	Which operation to do on the hierarchy (children).
pNamespaceName	The Namespace name on Add/Delete or the prefix to replace in case of replace.
pReplaceTo	The new Namespace Name or NULL in case of add or delete.
pAddRight	Whether to add the namespace on right-most or left-most side or other namespace.

Returns

return true if process successful.

See the C++ reference

bool ProcessObjectNamespace	(	FBComponent	arg1,
		FBNamespaceAction	arg2,
		str	arg3,
		str	arg4,
		object	arg5
	)

ProcessObjectNamespace.

Python Docstring:

ProcessObjectNamespace( (FBComponent)arg1, (FBNamespaceAction)arg2, (str)arg3 [, (str)arg4 [, (object)arg5]]) -> bool

C++ Signature:

bool ProcessObjectNamespace(FBNamespaceAction pNamespaceAction, const char * pNamespaceName, const char * pReplaceTo = ((void *) 0), bool pAddRight = true)

New Namespace name should only contains alphabet, digit and '_', Can't start with digit. This function is the same as ProcessNamespaceHierarchy except that it applies only on the current object and not to the object's children.

Parameters

pNamespaceAction	Which operation to do on the hierarchy (children).
pNamespaceName	The Namespace name on Add/Delete or the prefix to replace in case of replace.
pReplaceTo	The new Namespace Name or NULL in case of add or delete.
pAddRight	Whether to add the namespace on right-most or left-most side or other namespace.

Returns

return true if process successful.

See the C++ reference

int PropertyAdd	(	FBComponent	arg1,
		FBProperty	arg2
	)

Add a property to the component's property manager.

Python Docstring:

PropertyAdd( (FBComponent)arg1, (FBProperty)arg2) -> int

C++ Signature:

int PropertyAdd(ORSDK2018::FBProperty * pProperty)

Parameters

pProperty

The property to add to the property manager.

Returns

Index in the property array where property was inserted.

See the C++ reference

bool PropertyAddReferenceProperty	(	FBComponent	arg1,
		FBProperty	arg2
	)

Add a reference property to the component's property manager.

Python Docstring:

PropertyAddReferenceProperty( (FBComponent)arg1, (FBProperty)arg2) -> bool

C++ Signature:

bool PropertyAddReferenceProperty(ORSDK2018::FBProperty * pReferenceProperty)

Parameters

pReferenceProperty

The property to from an other object to add a reference to (property cannot be a custom ORSDK property).

Returns

True if the reference property could be added.

See the C++ reference

object PropertyCreate	(	FBComponent	arg1,
		str	arg2,
		FBPropertyType	arg3,
		str	arg4,
		object	arg5,
		object	arg6,
		FBProperty	arg7
	)

Create user or dynamic property.

Python Docstring:

PropertyCreate( (FBComponent)arg1, (str)arg2, (FBPropertyType)arg3, (str)arg4, (object)arg5, (object)arg6, (FBProperty)arg7) -> object

C++ Signature:

ORSDK2018::FBProperty * PropertyCreate(const char * pName, FBPropertyType pType, const char * pDataType, bool pAnimatable, bool pIsUser = false, ORSDK2018::FBProperty * pReferenceSource = ((void *) 0))

Parameters

pName	The name of the property.
pType	Type of the property. See enum FBPropertyType.
pDataType	DataType of the property.
pAnimatable	To specify if the property can be animated.
pIsUser	To specify if the property is available as a custom property or dynamic and attached to the object.
pReferenceSource	Specifies the property that a reference refers to.

See the C++ reference

FBPropertyList PropertyGetModifiedList	(	FBComponent	arg1,
		FBPlugModificationFlag	arg2
	)

Get list of properties which have been modified since last loading.

Python Docstring:

PropertyGetModifiedList( (FBComponent)arg1, (FBPlugModificationFlag)arg2) -> FBPropertyList

C++ Signature:

void PropertyGetModifiedList(ORSDK2018::FBArrayTemplate< ORSDK2018::FBProperty * > & pPropList, FBPlugModificationFlag pModificationFlags)

Parameters

pPropList	property list to hold the modified properties.
pModificationFlags	type of modification to query.

See the C++ reference

PropertyRemove	(	FBComponent	arg1,
		FBProperty	arg2
	)

Remove a Property from the component's Property manager.

Python Docstring:

PropertyRemove( (FBComponent)arg1, (FBProperty)arg2) -> None

C++ Signature:

void PropertyRemove(ORSDK2018::FBProperty * pProperty)

If the property was dynamically allocated, it is deleted.

Parameters

pProperty

The property to remove from the property manager.

See the C++ reference

SetObjectFlags	(	FBComponent	arg1,
		FBObjectFlag	arg2
	)

SetObjectFlags.

Python Docstring:

SetObjectFlags( (FBComponent)arg1, (FBObjectFlag)arg2) -> None

C++ Signature:

void SetObjectFlags(FBObjectFlag pFlags)

Parameters

pFlags

Set flag values. Note: this function overwrites all flags with those passed in parameter.

See the C++ reference

SetObjectStatus	(	FBComponent	arg1,
		FBObjectStatus	arg2,
		object	arg3
	)

Enable/Disable a specific Object Status.

Python Docstring:

SetObjectStatus( (FBComponent)arg1, (FBObjectStatus)arg2, (object)arg3) -> None

C++ Signature:

void SetObjectStatus(FBObjectStatus pStatus, bool pValue)

Parameters

pStatus	Status to change.
pValue	Value to change the status to.

See the C++ reference

Member Data Documentation

ORSDK2018::FBPropertyListComponent Components

List: List of components.

See the C++ reference

object FullName

ORSDK2018::FBPropertyString LongName

Read Write Property: Name and namespace for object.

See the C++ reference

ORSDK2018::FBPropertyString Name

Read Write Property: Unique name of object.

See the C++ reference

object OwnerNamespace

ORSDK2018::FBPropertyListComponent Parents

List: Parents.

See the C++ reference

ORSDK2018::FBPropertyManager PropertyList

Read Only Property: Manages all of the properties for the component.

See the C++ reference

FBPropertyBool Selected

Read Write Property: Selected property.

See the C++ reference
