Fill Analysis Quick Start Tutorial

In this tutorial, you simulate the filling phase in a part. The feed system is not included. The filling phase is the most important phase of the injection molding cycle. If there are problems with the filling of a part, the part quality is not optimal. In this tutorial, you will do the following:

1. Create a project
2. Import a CAD model
3. Investigate different injection locations
4. Mesh the CAD model
5. Check the mesh
6. Repair the mesh
7. Set processing conditions and run the analysis
8. View results

Before you begin, click here to download the model files for all the quick start tutorials.

When you are ready, click here to start the tutorial.
