#include <mobu-python-api.h>

Class Description

FBActor is used to link motion data to a character.

In MotionBuilder, an actor is a model used to link captured motion data to a character. Use functions in FBActor to set the body color, skeleton color, pivot color, marker size, pivot size, pivot information, etc. on an actor. These classes are under development and may change dramatically between versions. To obtain the list of actors present in a scene, you need to create an instance of class FBSystem, to obtain the current scene. The FBScene object holds the list of actors in the property Actors.

FBSystem lSystem;
FBScene* lScene = lSystem.Scene;
for( int lIdx = 0; lIdx < lScene->Actors.GetCount(); ++lIdx )
{
    FBTrace( "Actor[%d]: '%s'\n", lIdx, (char*)lScene->Actors[lIdx] );
}

The current actor selected in the Character tool can be obtained via the FBApplication object.

FBApplication lApplication;
FBActor* lActor = lApplication.CurrentActor;
if( lActor )
{
    FBTrace( "Current actor is: '%s'\n", (char*)lActor->Name );
}
else
{
    FBTrace( "No actor currently selected\n" );
}

Public Member Functions
	__reduce__ ()

	FBDelete (FBActor arg1)
	Actual Actor destructor. More...

	__init__ (object arg1, str arg2)
	Constructor. More...

	GetCurrentSkeletonState (...)
	Return the Current Skeleton State. More...

FBSkeletonState	GetDefaultSkeletonState (FBActor arg1)
	Return the Default Skeleton State. More...

bool	Snap (FBActor arg1, FBRecalcMarkerSetOffset arg2)
	Snap the marker set of the actor. More...

	UpdateValues (FBActor arg1, object arg2)
	Update Internal Values to be corresponding to the Given Evaluate Information. More...

	SetDefinitionScaleVector (FBActor arg1, FBSkeletonNodeId arg2, FBVector3d arg3, object arg4)
	Set Actor Scaling Definition. More...

	GetDefinitionScaleVector (FBActor arg1, FBSkeletonNodeId arg2, FBVector3d arg3)
	Get Actor Scaling Definition. More...

	SetDefinitionRotationVector (FBActor arg1, FBSkeletonNodeId arg2, FBVector3d arg3, object arg4)
	Set Actor Rotation Definition. More...

	SetActorTranslation (FBActor arg1, FBVector3d arg2)
	Translate Actor, similar to moving the hips of the Actor in the UI. More...

Public Member Functions inherited from FBConstraint
	__reduce__ ()

object	AnimationNodeInCreate (FBConstraint arg1, object arg2, FBModel arg3, str arg4)

object	__copy__ (FBConstraint arg1)

object	AnimationNodeOutCreate (FBConstraint arg1, object arg2, FBModel arg3, str arg4)
	Animation Node Creations (IN/OUT). More...

object	Clone (FBConstraint arg1)
	Clone the constraint. More...

bool	DeformerBind (FBConstraint arg1, FBModel arg2)
	Bind/Unbind pModel to deformation constraint. More...

bool	DeformerUnBind (FBConstraint arg1, FBModel arg2)

bool	Disable (FBConstraint arg1, FBModel arg2)
	Disable constraint on pModel. More...

	FreezeSRT (FBConstraint arg1, FBModel arg2, object arg3, object arg4, object arg5)
	Freeze current model state. More...

	FreezeSuggested (FBConstraint arg1)
	Suggest 'freeze'. More...

bool	ReferenceAdd (FBConstraint arg1, object arg2, FBModel arg3)
	Add a reference to a specified group. More...

object	ReferenceGet (FBConstraint arg1, object arg2, object arg3)
	Get a reference. More...

int	ReferenceGetCount (FBConstraint arg1, object arg2)
	Get number of references in a specified group. More...

int	ReferenceGroupAdd (FBConstraint arg1, str arg2, object arg3)
	Add a group of references. More...

int	ReferenceGroupGetCount (FBConstraint arg1)
	Return the number of reference groups. More...

int	ReferenceGroupGetMaxCount (FBConstraint arg1, object arg2)
	Get the maximum number of items that can exist in the reference group in question. More...

str	ReferenceGroupGetName (FBConstraint arg1, object arg2)
	Get the name of the reference group. More...

bool	ReferenceRemove (FBConstraint arg1, object arg2, FBModel arg3)
	Remove a reference to pModel from the group at pGroupIndex. More...

	RemoveAllAnimationNodes (FBConstraint arg1)
	Remove animation nodes. More...

	RestoreModelState (FBConstraint arg1, FBModel arg2)
	Restore the saved model state onto pModel. More...

	SaveModelState (FBConstraint arg1, FBModel arg2, object arg3, object arg4, object arg5)
	Save current state of pModel. More...

	SetupAllAnimationNodes (FBConstraint arg1)
	Setup animation nodes. More...

	Snap (FBConstraint arg1)
	Function Property: Snap constraint. More...

	SnapSuggested (FBConstraint arg1)
	Suggest 'snap'. More...

	__init__ (...)
	Constructor. More...

Public Member Functions inherited from FBBox
	__reduce__ ()

bool	AnimationNodeDestroy (FBBox arg1, FBAnimationNode arg2)
	Destroy an animation node. More...

	__init__ (object arg1, str arg2)
	Constructor. More...

object	AnimationNodeInGet (FBBox arg1)
	Get the (IN/OUT) animation node for this box. More...

bool	AnimationNodeIsUserData (FBBox arg1, FBAnimationNode arg2)
	Is the animation node user data? More...

object	AnimationNodeOutGet (FBBox arg1)

int	GetOutConnectorCount (FBBox arg1)
	Get the number of animation node outputs for this box. More...

int	GetInConnectorCount (FBBox arg1)
	Get the number of animation node inputs for this box. More...

object	GetOutConnector (FBBox arg1, object arg2)
	Get the animation node output associated with the given index. More...

object	GetInConnector (FBBox arg1, object arg2)
	Get the animation node input associated with the given index. More...

Public Member Functions inherited from FBComponent
	__reduce__ ()

FBPropertyList	PropertyGetModifiedList (FBComponent arg1, FBPlugModificationFlag arg2)
	Get list of properties which have been modified since last loading. More...

str	ClassName (FBComponent arg1)
	Get the class name. More...

	DisableObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	Disable a specific Object Flags. More...

	EnableObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	Enable a specific Object Flags. More...

bool	FBCreate (FBComponent arg1)
	Open Reality Creation function. More...

	FBDelete (FBComponent arg1)
	Open Reality deletion function. More...

	FBDestroy (FBComponent arg1)
	Open Reality destruction function. More...

FBObjectFlag	GetObjectFlags (FBComponent arg1)
	Get all Object Flags (concatenated). More...

bool	GetObjectStatus (FBComponent arg1, FBObjectStatus arg2)
	Check to see if an object status is enabled. More...

bool	HasObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	Check whether a specific object flag is enabled. More...

bool	Is (FBComponent arg1, object arg2)
	Returns true if object is of type TypeId. More...

bool	ProcessNamespaceHierarchy (FBComponent arg1, FBNamespaceAction arg2, str arg3, str arg4, object arg5)
	ProcessNamespaceHierarchy. More...

bool	ProcessObjectNamespace (FBComponent arg1, FBNamespaceAction arg2, str arg3, str arg4, object arg5)
	ProcessObjectNamespace. More...

int	PropertyAdd (FBComponent arg1, FBProperty arg2)
	Add a property to the component's property manager. More...

bool	PropertyAddReferenceProperty (FBComponent arg1, FBProperty arg2)
	Add a reference property to the component's property manager. More...

object	PropertyCreate (FBComponent arg1, str arg2, FBPropertyType arg3, str arg4, object arg5, object arg6, FBProperty arg7)
	Create user or dynamic property. More...

	PropertyRemove (FBComponent arg1, FBProperty arg2)
	Remove a Property from the component's Property manager. More...

	SetObjectFlags (FBComponent arg1, FBObjectFlag arg2)
	SetObjectFlags. More...

	SetObjectStatus (FBComponent arg1, FBObjectStatus arg2, object arg3)
	Enable/Disable a specific Object Status. More...

	HardSelect (FBComponent arg1)
	HardSelect. More...

object	GetOwnerFileReference (FBComponent arg1)
	Get the owner FileReference object. More...

	__init__ (...)
	Constructor. More...

Public Member Functions inherited from FBPlug
	__reduce__ ()

bool	BeginChange (FBPlug arg1)
	Begins a change on multiple plugs. More...

str	ClassName (FBPlug arg1)
	internal System vars. More...

bool	ConnectDst (FBPlug arg1, FBPlug arg2, FBConnectionType arg3)
	Add a destination connection. More...

bool	ConnectDstAt (FBPlug arg1, object arg2, FBPlug arg3, FBConnectionType arg4)
	Add a destination connection. More...

bool	ConnectSrc (FBPlug arg1, FBPlug arg2, FBConnectionType arg3)
	Add a source connection. More...

bool	ConnectSrcAt (FBPlug arg1, object arg2, FBPlug arg3, FBConnectionType arg4)
	Add a source connection. More...

	DisconnectAllDst (FBPlug arg1)
	Remove all destination connections. More...

	DisconnectAllSrc (FBPlug arg1)
	Remove all source connections. More...

bool	DisconnectDst (FBPlug arg1, FBPlug arg2)
	Remove a destination connection. More...

bool	DisconnectDstAt (FBPlug arg1, object arg2)
	Remove a destination connection at a specified index. More...

bool	DisconnectSrc (FBPlug arg1, FBPlug arg2)
	Remove a source connection. More...

bool	DisconnectSrcAt (FBPlug arg1, object arg2)
	Remove a source connection at a specified index. More...

	EndChange (FBPlug arg1)
	Ends a change on multiple plugs. More...

object	GetDst (FBPlug arg1, object arg2)
	Get a destination connection's plug at specified index. More...

int	GetDstCount (FBPlug arg1)
	Get destination connection count. More...

FBConnectionType	GetDstType (FBPlug arg1, object arg2)
	Get a destination connection's type at specified index. More...

object	GetOwned (FBPlug arg1, object arg2)
	Get the owned plug at specified index. More...

int	GetOwnedCount (FBPlug arg1)
	Get the owned plug count. More...

object	GetOwner (FBPlug arg1)
	Get the owner of this plug. More...

object	GetSrc (FBPlug arg1, object arg2)
	Get a source connection's plug at specified index. More...

int	GetSrcCount (FBPlug arg1)
	Get source connection count. More...

FBConnectionType	GetSrcType (FBPlug arg1, object arg2)
	Get a source connection's type at specified index. More...

bool	Is (FBPlug arg1, object arg2)
	Is( int pTypeId ) More...

bool	IsSDKComponent (FBPlug arg1)
	Return whether or not item is an SDK component. More...

	MoveSrcAt (...)

bool	ReplaceDstAt (FBPlug arg1, object arg2, FBPlug arg3)
	Replace a destination connection at a specified index. More...

bool	ReplaceSrcAt (FBPlug arg1, object arg2, FBPlug arg3)
	Replace a source connection at a specified index. More...

bool	SwapSrc (FBPlug arg1, object arg2, object arg3)
	Swap source connection at index A with source connection at index B. More...

	SetSelfModified (FBPlug arg1, FBPlugModificationFlag arg2, object arg3)
	Set the plug's self modification flag. More...

bool	GetSelfModified (FBPlug arg1, FBPlugModificationFlag arg2)
	Tell if the plug's self has changed. More...

	SetContentModified (FBPlug arg1, FBPlugModificationFlag arg2, object arg3)
	Set the plug's owned property/object's modification flag. More...

bool	GetContentModified (FBPlug arg1, FBPlugModificationFlag arg2)
	Tell if the plug's content has changed. More...

int	GetPlugConnectionModifiedList (FBPlug arg1, FBPlugList arg2, FBPlugModificationFlag arg3, object arg4)
	Get plug's modified src/dst property/object connection added/removed List. More...

bool	RevertModification (FBPlug arg1, FBPlugModificationFlag arg2)
	Revert the plug's modification to original status. More...

	__init__ (...)

method	staticmethod (function)

Public Member Functions inherited from FBPythonWrapper
	__reduce__ ()

	__init__ (...)

Public Attributes
FBPropertyColor	BodyColor
	Read Write Property: The color of the body of the actor. More...

FBPropertyVector3d	ChestPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	HeadPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	HipsPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftAnklePosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftCollarPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftElbowPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftFootPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftHipPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftKneePosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftShoulderPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	LeftWristPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyMarkerSet	MarkerSet
	Read Write Property: Associated marker set. More...

FBPropertyDouble	MarkerSetSize
	Read Write Property: The size of the markers of the actor. More...

FBPropertyVector3d	NeckPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyMarkerSet	OutputMarkerSet
	Read Write Property: Associated output marker set. More...

FBPropertyColor	PivotColor
	Read Write Property: The color of the pivot points of the actor. More...

FBPropertyDouble	PivotSize
	Read Write Property: The size of the pivot points of the actor. More...

FBPropertyVector3d	RightAnklePosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightCollarPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightElbowPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightFootPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightHipPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightKneePosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightShoulderPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyVector3d	RightWristPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyColor	SkeletonColor
	Read Write Property: The color of the skeleton of the actor. More...

FBPropertyVector3d	WaistPosition
	Read Write Property: Body part pivot of the actor. More...

FBPropertyAnimatableDouble	LeftHandIndexIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandIndexMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandIndexRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandIndexPinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandMiddleIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandMiddleMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandMiddleRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandMiddlePinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandRingIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandRingMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandRingRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandRingPinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandPinkyIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandPinkyMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandPinkyRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	LeftHandPinkyPinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandIndexIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandIndexMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandIndexRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandIndexPinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandMiddleIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandMiddleMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandMiddleRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandMiddlePinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandRingIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandRingMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandRingRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandRingPinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandPinkyIndex
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandPinkyMiddle
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandPinkyRing
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	RightHandPinkyPinky
	Read Write Property: Used to set blending coefficients. More...

FBPropertyAnimatableDouble	FKFingerMultiplier
	Read Write Property: Used to augment the amount of FK propagation for unmarkered intermediate finger phalanges. More...

FBPropertyAnimatableDouble	FKFingerTipMultiplier
	Read Write Property: Used to augment the amount of FK propagation for unmarkered finger tip phalanges. More...

FBPropertyAnimatableDouble	FKThumbTipMultiplier
	Read Write Property: Used to augment the amount of FK propagation for unmarkered thumb tip phalanges. More...

FBPropertyAnimatableBool	HumanFingerLimits
	Read Write Property: Enables/Disables human finger limits during actor solve. More...

FBPropertyBool	Visibility
	Read Write Property: Show or Hide the Actor Body. More...

FBPropertyBool	SkeletonVisibility
	Read Write Property: Show or Hide the Skeleton. More...

FBPropertyBool	PivotPointsVisibility
	Read Write Property: Show or Hide the Pivot Points. More...

object	HeadOffsetT

object	HeadOffsetR

object	NeckOffsetT

object	NeckOffsetR

object	ChestOffsetT

object	ChestOffsetR

object	LeftCollarOffsetT

object	LeftCollarOffsetR

object	RightCollarOffsetT

object	RightCollarOffsetR

object	LeftShoulderOffsetT

object	LeftShoulderOffsetR

object	RightShoulderOffsetT

object	RightShoulderOffsetR

object	LeftElbowOffsetT

object	LeftElbowOffsetR

object	RightElbowOffsetT

object	RightElbowOffsetR

object	LeftWristOffsetT

object	LeftWristOffsetR

object	RightWristOffsetT

object	RightWristOffsetR

object	WaistOffsetT

object	WaistOffsetR

object	HipsOffsetT

object	HipsOffsetR

object	LeftHipOffsetT

object	LeftHipOffsetR

object	RightHipOffsetT

object	RightIndexAOffsetR

object	RightIndexBOffsetT

object	RightIndexBOffsetR

object	RightIndexCOffsetT

object	RightIndexCOffsetR

object	RightMiddleAOffsetT

object	RightMiddleAOffsetR

object	RightMiddleBOffsetT

object	RightMiddleBOffsetR

object	RightMiddleCOffsetT

object	RightMiddleCOffsetR

object	RightRingAOffsetT

object	RightRingAOffsetR

object	RightRingBOffsetT

object	RightRingBOffsetR

object	RightRingCOffsetT

object	RightRingCOffsetR

object	RightPinkyAOffsetT

object	RightPinkyAOffsetR

object	RightPinkyBOffsetT

object	RightPinkyBOffsetR

object	RightPinkyCOffsetT

object	RightPinkyCOffsetR

object	ManipulateOffsets

FBPropertyBool	IKManip
	Read Write Property: Access to the IK Manip mode. More...

object	RightHipOffsetR

object	LeftKneeOffsetT

object	LeftKneeOffsetR

object	RightKneeOffsetT

object	RightKneeOffsetR

object	LeftAnkleOffsetT

object	LeftAnkleOffsetR

object	RightAnkleOffsetT

object	RightAnkleOffsetR

object	LeftFootOffsetT

object	LeftFootOffsetR

object	RightFootOffsetT

object	RightFootOffsetR

object	LeftThumbAOffsetT

object	LeftThumbAOffsetR

object	LeftThumbBOffsetT

object	LeftThumbBOffsetR

object	LeftThumbCOffsetT

object	LeftThumbCOffsetR

object	LeftIndexAOffsetT

object	LeftIndexAOffsetR

object	LeftIndexBOffsetT

object	LeftIndexBOffsetR

object	LeftIndexCOffsetT

object	LeftIndexCOffsetR

object	LeftMiddleAOffsetT

object	LeftMiddleAOffsetR

object	LeftMiddleBOffsetT

object	LeftMiddleBOffsetR

object	LeftMiddleCOffsetT

object	LeftMiddleCOffsetR

object	LeftRingAOffsetT

object	LeftRingAOffsetR

object	LeftRingBOffsetT

object	LeftRingBOffsetR

object	LeftRingCOffsetT

object	LeftRingCOffsetR

object	LeftPinkyAOffsetT

object	LeftPinkyAOffsetR

object	LeftPinkyBOffsetT

object	LeftPinkyBOffsetR

object	LeftPinkyCOffsetT

object	LeftPinkyCOffsetR

object	RightThumbAOffsetT

object	RightThumbAOffsetR

object	RightThumbBOffsetT

object	RightThumbBOffsetR

object	RightThumbCOffsetT

object	RightThumbCOffsetR

object	RightIndexAOffsetT

Public Attributes inherited from FBConstraint
FBPropertyBool	Active
	Read Write Property: Active state. More...

FBPropertyBool	Deformer
	Read Write Property: Is a deformer constraint? More...

ORSDK2018::FBPropertyString	Description
	Read Write Property: Long description of constraint. More...

FBPropertyBool	HasLayout
	Read Write Property: Does the constraint have a layout? More...

FBPropertyBool	Lock
	Read Write Property: Lock state. More...

FBPropertyAnimatableDouble	Weight
	Read Write Property: Weight of constraint. More...

Public Attributes inherited from FBBox
FBPropertyBool	Animatable
	Read Write Property: Is the box animatable. More...

FBPropertyBool	Live
	Read Write Property: Is live? More...

FBPropertyBool	RecordMode
	Read Write Property: Is recording? More...

const char *	UniqueName
	internal Unique name. More...

Public Attributes inherited from FBComponent
object	OwnerNamespace

ORSDK2018::FBPropertyListComponent	Components
	List: List of components. More...

ORSDK2018::FBPropertyString	Name
	Read Write Property: Unique name of object. More...

ORSDK2018::FBPropertyString	LongName
	Read Write Property: Name and namespace for object. More...

object	FullName

ORSDK2018::FBPropertyListComponent	Parents
	List: Parents. More...

ORSDK2018::FBPropertyManager	PropertyList
	Read Only Property: Manages all of the properties for the component. More...

FBPropertyBool	Selected
	Read Write Property: Selected property. More...

Public Attributes inherited from FBPythonWrapper
object	OnUnbind

pName	Name of new actor.
pObject	For internal use only. This parameter does not need to be specified by the developer.

GetDefinitionScaleVector	(	FBActor	arg1,
		FBSkeletonNodeId	arg2,
		FBVector3d	arg3
	)

SetDefinitionRotationVector	(	FBActor	arg1,
		FBSkeletonNodeId	arg2,
		FBVector3d	arg3,
		object	arg4
	)

pSkeletonId	Skeleton Node Id
pRotationVector	Actor Rotation value for the given ID
pSymmetricUpdate	Update right and left part at the same time

SetDefinitionScaleVector	(	FBActor	arg1,
		FBSkeletonNodeId	arg2,
		FBVector3d	arg3,
		object	arg4
	)

pSkeletonId	Skeleton Node Id
pScaleVector	Actor Scaling value for the given ID
pSymmetricUpdate	Update right and left part at the same time

FBActor Class Reference

Class Description

Public Member Functions

Public Attributes

Member Function Documentation

Member Data Documentation
